UniFi U7 Pro XG
$199 MSRP
UniFi U7 Pro XG: what it is & who it's for
A U7 Pro with a 10 GbE uplink for $10 more. Same six-stream tri-band radio, same 140 m² and 300+ client rating — the XG only earns its keep behind a 10 GbE or 5 GbE switch port. Multi-gig builds with 10 GbE switch ports where a single AP should never be uplink-bound — or a U7 Pro buyer who wants the port for later.
Specifications
| Wi-Fi Standard | Wi-Fi 7 (802.11be) |
|---|---|
| Bands | Tri-band (2.4 + 5 + 6 GHz) |
| 6 GHz Rate | 5.8 Gbps (BW320) |
| 5 GHz Rate | 4.3 Gbps (BW240) |
| 2.4 GHz Rate | 688 Mbps (BW40) |
| Spatial Streams | 6 |
| 5 GHz MIMO | 2×2 |
| Uplink Port | (1) 10 GbE RJ45 |
| Power Method | PoE+ |
| Max Power Draw | 22 W |
| Max Clients | 300+ |
| Coverage Area | 140 m² (1,500 ft²) |
| Dimensions | ⌀206 × 32.5 mm |
| Weight | 750 g |
| Max TX Power | 6 GHz 24 dBm · 5 GHz 26 dBm · 2.4 GHz 23 dBm |
| 5 GHz Antenna Gain | 5 dBi |
| 6 GHz Antenna Gain | 6 dBi |
| Operating Temp | -30 to 40 °C (-22 to 104 °F) |
Verdict
A U7 Pro with a 10 GbE uplink for $10 more. Same six-stream tri-band radio, same 140 m² and 300+ client rating — the XG only earns its keep behind a 10 GbE or 5 GbE switch port.
Pros
- 10 GbE RJ45 uplink for $10 over the U7 Pro
- Same tri-band six-stream Wi-Fi 7 radio as the U7 Pro (6 GHz at 5.8 Gbps)
- Sold in white or black
Cons
- On a 2.5 GbE switch port it performs as a U7 Pro — the uplink needs 5 or 10 GbE to matter
- 2×2 on 5 GHz — the Pro Max and Pro XGS run 4×4
- 22 W draw requires PoE+ (802.3at)
Best forMulti-gig builds with 10 GbE switch ports where a single AP should never be uplink-bound — or a U7 Pro buyer who wants the port for later.
