UniFi Pro Max 24 PoE
$799 MSRP
UniFi Pro Max 24 PoE: what it is & who it's for
The 2.5 GbE upgrade to the Pro 24. Same 400 W PoE, dual 10G SFP+, and Layer 3 — but eight of its ports run at 2.5 GbE, sixteen are PoE++, and the fabric grows to 112 Gbps. The pick when multi-gig APs or clients are in the plan. UniFi racks deploying Wi-Fi 6E/7 access points or 2.5 GbE clients that need multi-gig access ports without moving to a full 10G switch.
Specifications
| RJ45 Ports | (16) 1 GbE + (8) 2.5 GbE (8 PoE+, 16 PoE++) |
|---|---|
| Uplinks | (2) 10G SFP+ |
| PoE Ports | 24 |
| PoE Standards | 802.3at / bt |
| Total PoE Budget | 400 W |
| Switching Capacity | 112 Gbps |
| Forwarding Rate | 83 Mpps |
| Layer | Layer 2 + Layer 3 |
| Form Factor | Rackmount (1U) |
| Max Power Draw | 450 W (incl. PoE) / 50 W (excl. PoE) |
| Power Adapter | Internal |
| Management | UniFi Network |
| Max PoE per Port | 60 W (PoE++) |
| Non-Blocking Throughput | 56 Gbps |
| MAC Address Table | 16,000 |
| Power Redundancy | Yes (USP-RPS) |
| Dimensions | 442 × 325 × 44 mm |
| Weight | 5.1 kg |
| Supported Rack Depth | 400–1,200 mm |
Verdict
The 2.5 GbE upgrade to the Pro 24. Same 400 W PoE, dual 10G SFP+, and Layer 3 — but eight of its ports run at 2.5 GbE, sixteen are PoE++, and the fabric grows to 112 Gbps. The pick when multi-gig APs or clients are in the plan.
Pros
- 8 of 24 ports are 2.5 GbE — multi-gig for Wi-Fi 6E/7 APs
- 16 PoE++ ports (vs 8 on the Pro 24) for high-draw devices
- Same 400 W PoE, dual 10G SFP+, and Layer 3 as the Pro 24
- 112 Gbps switching, 83 Mpps; Etherlighting port LEDs
Cons
- About $100 more than the Pro 24
- Only a third of the ports are 2.5 GbE — the rest stay 1 GbE
- Rackmount 1U; overkill for a small wired footprint
Best forUniFi racks deploying Wi-Fi 6E/7 access points or 2.5 GbE clients that need multi-gig access ports without moving to a full 10G switch.
